Parker Compax3 User Manual

Parker EME
Introduction
192-120113 N08 C3I12T11 - December 2010
11
In this chapter you can read about:
Device assignment .......................................................................................................... 11
Scope of delivery ............................................................................................................. 12
Type specification plate ................................................................................................... 13
Packaging, transport, storage .......................................................................................... 14
Safety instructions ........................................................................................................... 16
Warranty conditions ......................................................................................................... 18
Conditions of utilization .................................................................................................... 19
1.1 Device assignment
This manual is valid for the following devices:
 Compax3S025V2 + supplement
 Compax3S063V2 + supplement
 Compax3S100V2 + supplement
 Compax3S150V2 + supplement
 Compax3S015V4 + supplement
 Compax3S038V4 + supplement
 Compax3S075V4 + supplement
 Compax3S150V4 + supplement
 Compax3S300V4 + supplement
 Compax3H050V4 + supplement
 Compax3H090V4 + supplement
 Compax3H125V4 + supplement
 Compax3H155V4 + supplement
 Compax3M050D6 + supplement
 Compax3M100D6 + supplement
 Compax3M150D6 + supplement
 Compax3M300D6 + supplement
 PSUP10D6
 PSUP20D6
With the supplement:
 F10 (Resolver)
 F11 (SinCos
©
)
 F12 (linear and rotary direct drives)
 I12 T11
1. Introduction

Parker Compax3 Specifications

General

Brand	Parker
Model	Compax3
Category	Servo Drives
Language	English
