Parker Compax3 User Manual

Control via RS232 / RS485 / USB
C3I12T11
308
192-120113 N08 C3I12T11 - December 2010
5.6 COM port protocol
In this chapter you can read about:
RS485 settings values ................................................................................................... 308
ASCII - record ................................................................................................................ 309
Binary record ................................................................................................................. 310
You can communicate with Compax3 in order to read or write objects via plug X10
( or X3 on the mains module of Compax3M) on the front via a COM port (max. 32
nodes).
As a rule 2 records are possible:
 ASCII record: simple communication with Compax3
 Binary record: fast and secure communication with Compax3 by the aid of block
securing.
Switching between the ASCII and the binary record via automatic record
detection.
Interface settings (see on page 388)
RS232: SSK1 (see on page 363)
RS485: as SSK27 (see on page 364) / RS485 is activated by +5V on X10/1.
USB: SSK33/03 (only for Compax3M)
5.6.1. RS485 settings values
If “Master=Pop” is selected, only the settings compatible with the Pops (Parker
Operator Panels) made by Parker are possible.
Please note that the connected Pop has the same RS485 setting values.
You can test this with the "PopDesigner" software.
"Master=General" makes all Compax3 settings possible.
You can use this address to allow the master to access multiple devices
simultaneously.
The device address of the connected Compax3 can be set here.
Adjust the transfer speed (baud rate) to the master.
Please choose between two-wire and four-wire RS485 (see on page 61).
Adjust the protocol settings to the settings of your master.
Wiring
Multicast Address
Device Address
Baud rate
Cable type
Protocol
