1.7.3. Conditions of utilization for UL certification Compax3M
UL-approval for PSUP/Compax3M
conform to UL:
according to UL508C
Certified
E-File_No.: E235342
The UL certification is documented
by a “UL” logo on the device (type
specification plate).
Conditions of utilization
The devices are only to be installed in a degree of contamination 2 environment
(maximum).
The devices must be appropriately protected (e.g. by a switching cabinet).
Tightening torque of the field wiring terminals ( green Phoenix plugs)
Device X40: Ballast resistor X41: Mains connector X9: 24VDC
PSUP10
0.5 Nm (4.43Lb.in) 1.2 Nm (10.62Lb.in)
1.2 Nm
(10.62Lb.in)
PSUP20
0.5 Nm (4.43Lb.in) 1.7 Nm (15Lb.in)
1.2 Nm
(10.62Lb.in)
PSUP30
UL approval in preparation
Device X43: Motor connector X15: Temperature monitoring
C3M050-150
0.5Nm (4.43Lb.in) 0.22Nm (1.95Lb.in)
C3M300
1.2Nm (10.62Lb.in) 0.22Nm (1.95Lb.in)
Temperature rating of field installed conductors shall be at least 60°C Use copper
lines only
Please use the cables described in the accessories chapter (see on page 323,
see on page 324), they feature a temperature rating of at least 60°C.
Maximum Surrounding Air Temperature: 40°C.
Suitable for use on a circuit capable of delivering not more than 5000 rms
symmetrical amperes and 480 volts maximum.
Caution!
Danger of electric shock.
Discharge time of the bus capacitor is 10 minutes.
The drive provides internal motor overload protection.
This must be set so that 200% of the motor nominal current are not exceeded.
Cable cross-sections
Mains input: corresponding to the recommended fuses.
Motor cable: corresponding to the Nominal output currents (see on page 375,
see on page 376)
Maximum cross-section limited by the terminals mm
2
/ AWG
Line cross-sections of the power connections (on the device bottoms)
Compax3 device:
Cross-section: Minimum... Maximum [with conductor sleeve]
M050, M100, M150
0.25 ... 4 mm
2
(AWG: 23 ... 11)
M300
0.5 ... 6 mm
2
(AWG: 20 ... 10)
PSUP10
Mains supply: 0.5 ... 6 mm
2
(AWG: 20 ... 10)
Braking resistor: 0.25 ... 4 mm
2
(AWG: 23 ... 11)
PSUP20 & PSUP30
Mains supply: 0.5 ... 16 mm
2
(AWG: 20 ... 6)
Braking resistor: 0.25 ... 4 mm
2
(AWG: 23 ... 11)
