Setting up Compax3
C3I12T11
192-120113 N08 C3I12T11 - December 2010
4.4.7.4 Tips
1 Speed too low
(with reverse operation)
Increase maximum speed and adapt travel
range*
2 Speed too low
(with continuous operation)
Increase maximum speed
3 Test movement missing A test movement is important for drives with
high friction or with mechanical slack points
(play).
4 No error detected
Please note the boundary conditions (see
on page 244).
5 Speed too low and amplitude of
the excitation signal too small
(with reverse operation)
Increase amplitude of the excitation signal;
increase maximum speed and adapt travel
range*
6
Speed too low and
amplitude of the excitation
signal too small
(with continuous operation)
Increase amplitude of the excitation signal;
increase maximum speed.
7
amplitude of the excitation
Increase amplitude of the excitation signal
or / and
activate an appropriate test movement
8 amplitude of the excitation
signal too small
Increase the amplitude of the excitation
signal.
9 Following error occurred Increase the parameter "permissible
following error" or decrease the amplitude of
the excitation signal.
*if the travel range is too short, the speed is not increased, as the drive does not
reach the maximum speed.
