Control
via R
S232 /
RS485 / USB
C3I12T11
306
192
-
120113 N08 C3I12T11
-
Decem
ber 2010
5.5.7.
C3 settings for RS
485 two
wire operat
ion
C3 ServoManager
RS485 wizard settings:
download
with co
nfigurat
ion in RS
232 m
ode°!
Communicati
on settings C3S/C3M:
Object
Function
Value
810.1
Protocol
16 (two w
ire)
810.2
Baud rate
115200
810.3
NodeAddress
1..254
810.4
Multicast Add
res
s
307
309
