Parker Compax3 User Manual

Compax3 Accessories
C3I12T11
364
192-120113 N08 C3I12T11 - December 2010
10.8.2. RS485 cable to Pop
SSK27: Connection Pop - Compax3 - Compax3 - ...
5
3
Pin 1
7
Pin 1
4 mm 6 mm
26 mm
7 - 13
1 - 4
15
Lötseite
solder side
1
2
3
4
5
6
7
8
9
NC
NC
NC
Länge / Length A
Länge / Length B
Pin 1
Pin 1
Länge / Length B
5
3
7
1
NC 2,4,6,8
TxD_RxD
GND
Lötseite
solder side
1
2
3
4
5
6
7
8
9
BN
WH
GN
YE
TxD_RxD
TxD_RxD
GND
TxD_RxD
CHA+
CHA-
GND
BN
WH
GN
YE
9
BN
WH
YE
1
NC 2,4,6,8
9
RD
RD
X2
X3
X4
14
6
5
R21 nur im letzten Stecker
8
11
15
R21 only on the last connector
Schirm großflächig auf Gehäuse legen
Place sheath over large area of housing
Schirm großflächig auf Gehäuse legen
Place sheath over large area of housing
Brücke /
Bridge
Brücke /
Bridge
Schirm großflächig auf Gehäuse legen
Place sheath over large area of housing
Compax3_n
Compax3_2
Compax3_1
R21 = 220 Ohm
(6
Order code: SSK27/nn/..
Length A (Pop - 1. Compax3) variable (the last two numbers according to the
length code for cable, for example SSK27/nn/01)
Length B (1. Compax3 - 2. Compax3 - ... - n. Compax3) fixed 50 cm (only if there is
more than 1 Compax3, i.e. nn greater than 01)
Number n (the last two digits)
Examples include:
SSK27/05/.. for connecting from Pop to 5 Compax3.
SSK27/01/.. for connecting from Pop to one Compax3
