Compax3 device description
C3I12T11
76
192-120113 N08 C3I12T11 - December 2010
3.9.3.3 Mounting distances, air currents Compax3H1xxV4
J
I
K
M
L
in mm
I J K L M
C3H1xxV4
0 0 25 70 70
