Introduction
192-120113 N08 C3I12T11 - December 2010
19
1.7 Conditions of utilization
In this chapter you can read about:
Conditions of utilization for CE-conform operation ........................................................... 19
Conditions of utilization for UL certification Compax3S .................................................... 22
Conditions of utilization for UL certification Compax3M .................................................... 23
Conditions of utilization for UL certification Compax3H .................................................... 24
Current on the mains PE (leakage current) ...................................................................... 25
Supply networks .............................................................................................................. 25
1.7.1. Conditions of utilization for CE-conform operation
- Industry and trade -
The EC guidelines for electromagnetic compatibility 2004/108/EC and for electrical
operating devices for utilization within certain voltage limits 2006/95/EC are fulfilled
when the following boundary conditions are observed:
Operation of the devices only in the condition in which they were delivered,
i.e. with all housing panels.
In order to ensure contact protection, all mating plugs must be present on the
device connections even if they are not wired.
Please respect the specifications of the manual, especially the technical
characteristics (mains connection, circuit breakers, output data, ambient
conditions,...).
1.7.1.1 Conditions of utilization mains filter
A mains filter is required in the mains input line if the motor cable exceeds a certain
length. Filtering can be provided centrally at the system mains input or separately
for each device or with C3M for each axis system.
Use of the devices in a commercial and residential area (limit value class in
accordance with EN 61800-3)
The following mains filters are available for independent utilization:
Device:
Compax3S
Limit value
class
Motor cable length
Mains filter
Order No.:
S0xxV2 C2 < 10 m without
C2 > 10 m, < 100 m NFI01/01
S1xxV2,
S0xxV4, S150V4
C2 < 10 m without
C2 > 10 m, < 100 m NFI01/02
S300V4 C3 < 10 m without
C2, C3 > 10 m, < 100 m NFI01/03
Device:
Compax3H
Limit value
class
Motor cable length
Mains filter
Order No.:
H050V4 C2 < 10 m without
C2 > 10 m, < 50 m NFI02/01
H090V4 C2 < 10 m without
C2 > 10 m, < 50 m NFI02/02
H1xxV4 C2 < 10 m without
C2 > 10 m, < 50 m NFI02/03
Mains filter:
