Setting up Compax3

C3I12T11

162

192-120113 N08 C3I12T11 - December 2010

4.3.3.1 Object for the load control (overview)

No. Object name Object Format PD

Valid

begin

ning

410.6 C3.LimitPosition_LoadControlMaxPosDiff Position difference load-motor (error threshold) C4_3 no VP

680.23 C3.StatusPosition_LoadControlActual Actual position of the load C4_3 no -

680.20 C3.StatusPosition_LoadControlDeviation Position difference load-motor (unfiltered) C4_3 no -

680.22 C3.StatusPosition_LoadControlDeviationFiltered Position difference load-motor (filtered) C4_3 no -

680.21 C3.StatusPosition_LoadControlDeviationMax Maximum position difference load-motor C4_3 no -

681.20 C3.StatusSpeed_LoadControl Speed of the load feedback (unfiltered) C4_3 no -

681.21 C3.StatusSpeed_LoadControlFiltered Speed of the load feedback (filtered) C4_3 no -

2201.2 C3Plus.LoadControl_Command Load control command mode I16 no

immed

iately

2201.1 C3Plus.LoadControl_Enable Activate Load control I16 no

immed

iately

2201.11 C3Plus.LoadControl_FilterDenominator Time constant of position difference filter U32 no VP

2201.3 C3Plus.LoadControl_Status Load control status bits I16 no -

2201.12 C3Plus.LoadControl_VelocityFilter

Time constant of the load-speed filter for the

load feedback

I16 no VP

4.3.3.2 Objects for load control

Detailed information on the topic of "objects for load control" can be found in the

online help of the device.
