RL78/F13, F14 CHAPTER 27 SAFETY FUNCTIONS
R01UH0368EJ0210 Rev.2.10 1591
Dec 10, 2015
(1) Error address store register (ERADR)
Figure 27-8. Format of Error Address Store Register (ERADR)
Address: F0200H After reset: 00H R/W
Symbol 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
ERADR ERAD
ERAD Bit error address
0000H to FFFFH Address when a bit error interrupt request is generated
Cautions 1. Access the ERADR register in word units.
2. The register value is updated each time a bit error interrupt request is generated.
(2) 1-bit error detection interrupt enable register (ECCIER)
Figure 27-9. Format of 1-bit Error Detection Interrupt Enable Register (ECCIER)
Address: F0202H After reset: 00H R/W
Symbol 7 6 5 4 3 2 1 0
ECCIER - - - - - - - IEN
IEN 1-bit error detection interrupt enable bit
0 Interrupt disabled
1 Interrupt enabled
Cautions 1. Bits 1 to 7 of the ECCIER register are always read as 0. The write value should always be
0.
2. INTRAM interrupt request occurs regardless of the value of ECCIER on two bits error.
<R>
