SERVICE PROGRAM MODE 10 August, 2001
4-6
4.2.2 SERVICE PROGRAM MODE TABLES
Service Table Key
Notation What it means
[range / default /
step]
Example: [-9 ~ +9 / +3.0 / 0.1 mm step]. The setting can be
adjusted in the range ±9, the setting is reset to +3.0 after an
NVRAM reset, and the value can be changed in 0.1 mm steps
with each key press.
italics Comments added for reference.
*
Value stored in NVRAM. After a RAM reset, this default value
(factory setting) is restored.
1111 An SP number set in bold-italic denotes a “Special Service
Program” mode setting that appears only after entering the SP
mode by pressing ' and Copy SP together. (☛ 4.2.1)
DFU
Denotes “Design or Factory Use”. Do not change this value.
Japan only
The feature or item is for Japan only. Do not change this value.
(S) Sideways feed direction
(L) Lengthwise feed direction
SP1-XXX: Feed
1
Mode Number/Name Function/[Setting]
Leading Edge Registration
1 Paper Tray Feed
2 By-pass Feed
001*
3 Duplex, Side2
Adjusts the printing leading edge registration from
each paper feed station using the Trimming Area
Pattern (SP4-417, No.15).
Use the ! key to toggle between + and – before
entering the value.
The specification is 3 ± 2 mm.
See “Replacement and Adjustment - Copy Adjustment”
for details.
[+9.0 ~ –9.0 / +0.0 / 0.1 mm/step]
Side-to-Side Registration
1 1st Paper Feed
2 2nd Paper Feed
3
3rd Paper Feed:
optional PFU tray 1 or
optional LCT
4
4th Paper Feed:
optional PFU tray 2
5 By-pass Feed
002*
6 Duplex, Side2
Adjusts the printing side-to-side registration from each
paper feed station using the Trimming Area Pattern
(SP4-417, No.15).
Use the ! key to toggle between + and – before
entering the value. The specification is 2
±
1.5 mm.
See “Replacement and Adjustment - Copy Adjustment”
for details.
[+9.0 ~ –9.0 / +0.0 / 0.1 mm/step]
Paper Feed Timing
1 1st Paper Feed
2 2nd, 3rd, 4th Paper
Feed, LCT, and By-pass
Feed
Adjusts the paper feed clutch timing at registration.
The paper feed clutch timing determines the amount of
paper buckle at registration. (A larger setting leads to
more buckling.)
[0 ~ 10 / 5 / 1 mm/step]
003*
3 Duplex, Side2
[0 ~ 20 / 6 / 1 mm/step]
