Ricoh Russian-C2a User Manual

10 August, 2001 LEDS
4-77
Service
Tables
4.7 LEDS
Controller
Number Normal
Controller Software
Download
Error
LED 1 Off Blinking Off
LED 2 Blinking Blinking Lit or Off
LED 3
(+5V line)
Lit Lit Lit
SBCU
Number Normal
SBCU Software
Download
Error
LED 1 Lit Lit Off or Blinking
LED 2
Blinking Lit
Lit (except downloading)
or Off
IPU
Number Normal Error
LED 1 Lit Off or Blinking
4.8 DIP SWITCHES
Controller: DIP SW2
DIP SW No. ON OFF
1 IC Card Boot System ROM Boot
2
3
4
Keep at “OFF”
SBCU: DIP SW102
DIP SW No. Function ON OFF
1
2
3
Destination
On: Japan
On
On
Off: NA
On
On
On: EU/Asia
Off
On
Off: Not Used
Off
On
4 Not used OFF (Do not change)
