TRANSFER UNIT 10 August, 2001
6-16
6.4.2 IMAGE DENSITY SENSOR
1. Open the right cover [A].
2. Remove the unit band [B].
3. Remove the right cover [A] (1 connector),
4. Remove the sub right cover [C] (2 hooks).
5. Replace the image density sensor [D] (1 connector).
6. Initialize the new sensor with SP 2-935.
B027R201.WMF
B027R202.WMF
[A]
[C]
[D]
[B]
