10 August, 2001 SERVICE PROGRAM MODE
4-31
Service
Tables
4
Mode Number/Name Function/[Setting]
HDD Formatting Select the desired SP, then press Execute on the
touch panel to format each HDD partition.
Note: After execution, turn the main power switch off
and on.
1 All Initializes the entire hard disk.
2 Image Files
Initializes documents stored in document server mode,
stamp print data, scanner send data, fax send data.
3 NetFiles Initializes network file application thumbnail images.
4 Job Log
Initializes job logging data (for Poplar server) DFU
5 Printer Fonts Initializes printer fonts and stored fonts.
911*
9 Debug
DFU
920 Scanning (Factory)
DFU
Sensor Condition
1 Platen Cover sensor Checks the following sensors in the scanner unit.
[0 = Opened, 1 = Closed]
930*
2 Scanner HP Sensor [0 = Opened, 1 = Closed]
SP5-XXX: Mode
5
Mode Number/Name Function/[Setting]
mm/inch Selection024*
Selects whether mm or inches are used in the display.
Note: After selecting the number, you must turn the
main power switch off and on.
Eur./Asia model
[0 = mm / 1 = inch]
American model
[0 = mm / 1 = inch]
A3/DLT Double Count104*
Specifies whether the counter is doubled for A3/11" x
17" paper.
If “Yes” is selected, the total counter (mechanical
counter) and the current user code counter counts up
twice when A3/11" x 17" paper is used.
[0 = No / 1 = Yes]
ADS Level Selection106*
Selects the image density level that is used in ADS
mode.
[1 ~ 7 / 4 / 1 notch/step]
Option Counter Type113*
Selects the optional counter type.
Japan only DFU
[0 = No, 1 = Key Card1, 2 = Key Card2, 3 = Pre-paid
Card, 4 = Coin lock, 5 = MF key card]
118* Disable Copying
DFU
Opt. Counter Reset Setting120*
This SP is for Japan only. Do not change the value.
[0 = Yes / 1 = Stand-by / 2 = None]
To Next Page
