10 August, 2001 SELF-DIAGNOSTIC MODE
7-13
Trouble-
shooting
7.2.2 DETAILED SELF-DIAGNOSTIC MODE
In addition to the self-diagnostic test initiated every time the main machine is
powered on, you can set the machine in a more detailed diagnostic mode manually
in order to test other components or conditions that are not tested during self-
diagnosis after power on. The following device is required in order to put the
machine in the detailed self-diagnosis mode.
No. Name
G02119350 Parallel Loopback Connector
Executing Detailed Self-Diagnosis
Follow this procedure to execute detailed self-diagnosis.
1. Switch off the machine, and connect the parallel loopback device to the
Centronics I/F port.
2. Hold down ", press and hold down #, and then while pressing both keys at
the same time, switch on the machine.
You will see “Now Loading” on the touch-panel, and then you will see the
results of the test.
To Next Page
