SERVICE PROGRAM MODE 10 August, 2001
4-62
ARDF Output Check (SP6-008)
1. Open SP mode SP6-008.
2. Select the SP number that corresponds to the component you wish to check.
(Refer to the table below.)
3. Press On then press Off to test the selected item. You cannot exit and close
this display until you click Off to switch off the output check currently executing.
No. Description
1 Feed Motor (Forward)
2 Feed Motor (Reverse)
3 Transport Motor (Forward)
4 Feed Clutch
5 Pick-up Solenoid
6 Junction Gate Solenoid
7 Stamp Solenoid
Finisher Output Check (SP6-118)
1. Open SP mode SP6-118.
2. Select the SP number that corresponds to the component you wish to check.
(Refer to the table below.)
3. Press On then press Off to test the selected item. You cannot exit and close
this display until you click Off to switch off the output check currently executing.
No. Description
1000-sheet finisher 500-sheet finisher
1 Upper Transport Motor Main Motor
2 Shift Tray Lift Motor Output Tray Motor
3 Staple Hammer Motor Stapler Motor
4 Shift Motor Jogger Motor
5 Lower Transport Motor Not Used
6 Shift Tray Exit Motor Not Used
7 Tray Junction Gate Solenoid Not Used
8 Jogger Motor Not Used
9 Stapler Motor Not Used
10 Stapler Junction Gate Solenoid Not Used
11 Positioning Roller Solenoid Not Used
12 Stack Feed-out Motor Not Used
13 Exit Guide Plate Motor Not Used
14 Not Used Paddle Roller Solenoid
15 Not Used Exit Unit Gear Solenoid
16 Not Used Stack Height Lever Solenoid
17
