DRIVE LAYOUT 10 August, 2001
1-14
1.6 DRIVE LAYOUT
1. Scanner Drive Motor
2. Main Motor
3. Registration Clutch
4. Upper Paper Feed Clutch
5. Upper Transport Clutch
6. Lower Paper Feed Clutch
7. Lower Transport Clutch
B027V301.WMF
B027V302.WMF
1
2
3
4
5
6
7
Scanner
Fusing
PCU/Transfer Drive
