Printing User Information on Paper
The start time of the print job, information on the person who prints it (name or login user name), printer
number and printer's IP address can be compulsorily embedded on printed sheets. This function is called
Compulsory Security Stamp.
Always printing out information on the person printing the job is effective for discouraging information
leakage. It can also be used for identifying sources of information leakage.
1. Log in as the machine administrator from Web Image Monitor.
2. Point to [Device Management], and then click [Configuration].
3. Click [Compulsory Security Stamp] under "Device Settings".
4. Select [On] for "Compulsory Security Stamp".
5. Select the item to be stamped.
You can stamp an item by selecting [Stamp].
Any items that [Do not Stamp] is specified for will not be printed.
Date/Time
The job start time will be printed.
Printout User Name
If "Stamp User Name" is selected, the "Name" in the Address Book will be printed.
If "Stamp Login User Name" is selected, the "Login User Name" in the "Auth. Info" in the
Address Book will be printed.
If user authentication or User Code authentication has not been configured, the name of the
person printing the job will not be printed.
Machine ID
The numbers displayed as the "Serial No. of Machine" in [Inquiry] will be printed.
Machine IP Address
The printer's IP address will be printed. If there are both IPv4 and IPv6 addresses, the IPv4
address will be printed. If no IP address has been configured, this will be left blank.
6. Specify "Adjust Stamp Position".
7. Click [OK].
8. Log out.
1. Log in as the machine administrator from the control panel.
6. Preventing the Leaking of Documents
168

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Ricoh SP 4520DN and is the answer not in the manual?

Ricoh SP 4520DN Specifications

General IconGeneral
ColorNo
Duplex printingYes
Print technologyLED
Maximum resolution1200 x 1200 DPI
Time to first page (black, normal)5 s
Print speed (black, normal quality, A4/US Letter)40 ppm
Product colorWhite
Display diagonal4.3 \
Maximum duty cycle150000 pages per month
Number of print cartridges-
Page description languagesPCL 5e, PCL 6, PostScript 3
Total input capacity600 sheets
Total output capacity250 sheets
Maximum input capacity1600 sheets
AC input voltage220 - 240 V
AC input frequency50 - 60 Hz
Power consumption (max)1110 W
Power consumption (off)0.58 W
Power consumption (printing)1740 W
Internal memory512 MB
Processor frequency533 MHz
Compatible memory cardsSD
Maximum internal memory1024 MB
Other operating systems supportedNovell NetWare 6.x
Server operating systems supportedWindows Server 2003, Windows Server 2003 R2, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 R2 x64, Windows Server 2008 x64, Windows Server 2012, Windows Server 2012 R2, Windows Server 2012 R2 x64, Windows Server 2012 x64
Windows operating systems supportedWindows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64
Paper tray media typesEnvelopes, Plain paper, Pre-Printed, Recycled paper, Thick paper, Thin paper
Paper tray media weight52 - 162 g/m²
ISO A-series sizes (A0...A9)A4, A5, A6
ISO B-series sizes (B0...B9)B5, B6
Maximum ISO A-series paper sizeA4
Standard interfacesEthernet, USB 2.0
Optional connectivityWireless LAN
Weight and Dimensions IconWeight and Dimensions
Depth392 mm
Width370 mm
Height306 mm
Weight14000 g
