Offset Range Meaning Error Code
16-n IOC Triplets
•
Color Specification Triplet. This optional triplet can be
placed at the end of the IOC command to specify the
foreground color of the object area, before any object
data is placed on the object area. Any number of IOC
triplets can be received, they are processed in the order
received and the resulting color of the object area
depends on the last instance of the triplet received. For
details, see "Color Specification", IPDS Technical
Reference 1.
• Presentation Space Reset Mixing Triplet. This optional
triplet can be placed at the end of the IOC command to
specify whether or not an object area is reset to the color
of medium before any object data is placed on the object
area. Any number of IOC triplets can be received, they
are processed in the order received and the resulting
color of the object area depends on the last instance of
the triplet received. For details, see "Presentation Space
Reset Mixing", IPDS Technical Reference 1.
• The Replicate and Trim Mapping Control option is supported only when the IPDS Menu PRINT
MODE item is set to ENH (Enhanced 600 dpi).
Image Data Descriptor
This is a REQUIRED data structured field in the Write Image Control 2 command. It specifies parameters
that define the image presentation space size and resolution.
Offset Range Meaning Error Code
0-1 X'000F' -
X'xxxx'
LENGTH of Image Data Descriptor X'0202..0
5'
2-3 X'A6FB' STRUCTURED FIELD ID X'020B..
05'
4-5 X'0000' Reserved
IO Image Commands
139
