The set of valid values differs according to which forms module configuration is installed and selected by
the operator. Since printers are capable of supporting multiple installed input bins, multiple configuration
combinations are possible. All input media sources are described below.
When the number of installed input bins changes, the printer is POR'd and initial machine settings are
established. When the bin configuration changes exception X'0101..00' is reported to the host.
•
Actual tray capacities are determined by media weight. The capacities indicated in the table are
the maximum allowable.
• The machine supports media source tray numbering. Media source values in the SIMS support
tables represent the default settings when the printer is initially installed. For this machine, the
printer's control panel menu mode is provided to allow customers to specify the source tray
numbers to meet requirements of legacy applications.
• For the tray in which "envelope" has been specified as the paper type, the tray values of the tray ID
are (in ascending for each respective tray that is installed) as follows: X'8040', X'8041', etc. If a
different paper type is specified for the tray, the tray values of the tray ID are (in ascending for
each respective tray that is installed) as follows: X'8000', X'8001', etc. In regards to the bypass
tray and default tray, even if you specify "envelope" as the paper type, the tray value will not be
changed.
Offset Range Meaning Error Code
0-1 X'1500' SELECT INPUT MEDIA SOURCE
Execute Order Home State (XOH)
99
