SATO CL4NX User Manual

NFC Interface Connection (Standard)
106
The communication condition settings must be configured according to your network environment. Set
the IP address of the printer.
The IP address of the printer can be set through the printer's [Interface] menu or the All-In-One Tool.
• To use the printer driver, the communication protocol must be set to Status4. (The
initial value of the communication protocol for the printer's LAN interface is Status4
ENQ.)
Bluetooth Interface Connection (Standard)
The printer can perform wireless communication with Bluetooth-compatible computers placed within
about 10 meters (32.8 feet) from it.
Make sure that the Bluetooth function of the printer and the computer is enabled, and then add the
printer as a Bluetooth device on the computer.
The printer's Bluetooth function is enabled by default and can be configured from the [Interface] menu
or the All-In-One Tool.
• To use the printer driver, the communication protocol must be set to Status4. (The
initial value of the communication protocol for the printer's Bluetooth interface is
Status4 Multi.)
NFC Interface Connection (Standard)
The NFC interface of the printer supports a handover function that simplifies the Bluetooth/Wi-Fi
connection setup with Android devices.
The handover function only performs the connection setup, such as the pairing and authentication with
NFC, and passes the actual interface to the more advanced Bluetooth and Wi-Fi when communicating
between NFC supported devices. In general, the pairing and authentication require some procedures
to enter authentication information, but the connection can be completed simply by holding the Android
devices over the printer while using NFC.
Touch the NFC antenna (1) of the printer with the NFC mark on the Android device.

SATO CL4NX Specifications

General

Wi-Fi	No
Ethernet LAN	Yes
Flash memory	2000 MB
Storage media	Flash
Internal memory	256 MB
Built-in barcodes	Code 39, Code 93, Code-128 Codabar Library, EAN13, EAN8, GS1 DataBar, Industrial 2/5, Interleaved 2/5, Matrix 2/5
Internal storage capacity	2 GB
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	30 - 90 %
Operating relative humidity (H-H)	30 - 80 %
Maximum roll diameter	220 mm
Maximum printing width	104 mm
Printing media thickness	0.06 - 0.26 µm
Display type	LCD
Product color	Black
Display diagonal	3.5 \
Display resolution	320 x 240 pixels
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	50 - 60 Hz
USB connector	USB Type-A / USB Type-B
Bluetooth version	3.0
Serial interface type	RS-232C
USB 2.0 ports quantity	2
Connectivity technology	Wired & Wireless
Type	POS printer
Print speed	10 ips
Print technology	Direct thermal / Thermal transfer
Maximum resolution	203 x 203 DPI

Weight and Dimensions

Depth	457 mm
Width	271 mm
Height	321 mm
Weight	15000 g
