Usable Media and Ribbon
Media
• Use genuine media made by SATO.
Type
• Media roll (Face-in wound/face-out wound)
• Fan-fold media
Size
• Continuous
Item CL4NX CL6NX
Media Length
203 dpi
6 to 2497 mm (0.24" to 98.30")
305 dpi
6 to 1497 mm (0.24" to 58.94")
609 dpi
6 to 397 mm (0.24" to 15.63")
203 dpi
16 to 2497 mm (0.63" to 98.30")
305 dpi
16 to 1497 mm (0.63" to 58.94")
Media Length (With
Liner)
203 dpi
9 to 2500 mm (0.35" to 98.42")
305 dpi
9 to 1500 mm (0.35" to 59.05")
609 dpi
9 to 400 mm (0.35" to 15.75")
203 dpi
19 to 2500 mm (0.75" to 98.42")
305 dpi
19 to 1500 mm (0.75" to 59.05")
Media Width
• 22 to 128 mm (0.87" to 5.04") • 47 to 177 mm (1.85" to 6.96")
Media Width (With
Liner)
• 25 to 131 mm (0.98" to 5.16") • 50 to 180 mm (1.97" to 7.01")
*Above pitch and width are valid for die-cut labels. For media without liner like tags, refer to the
value 'with liner'.
• Tear-Off/Cutter

SATO CL4NX Specifications

General

Wi-Fi	No
Ethernet LAN	Yes
Flash memory	2000 MB
Storage media	Flash
Internal memory	256 MB
Built-in barcodes	Code 39, Code 93, Code-128 Codabar Library, EAN13, EAN8, GS1 DataBar, Industrial 2/5, Interleaved 2/5, Matrix 2/5
Internal storage capacity	2 GB
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	30 - 90 %
Operating relative humidity (H-H)	30 - 80 %
Maximum roll diameter	220 mm
Maximum printing width	104 mm
Printing media thickness	0.06 - 0.26 µm
Display type	LCD
Product color	Black
Display diagonal	3.5 \
Display resolution	320 x 240 pixels
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	50 - 60 Hz
USB connector	USB Type-A / USB Type-B
Bluetooth version	3.0
Serial interface type	RS-232C
USB 2.0 ports quantity	2
Connectivity technology	Wired & Wireless
Type	POS printer
Print speed	10 ips
Print technology	Direct thermal / Thermal transfer
Maximum resolution	203 x 203 DPI

Weight and Dimensions

Depth	457 mm
Width	271 mm
Height	321 mm
Weight	15000 g
