[Tools] Menu
452
[Tools] Menu
The following settings are available in the [Tools] menu:
Test Print
Perform a test print.
HEX-Dump
Save the hex dump print data or dump data from the receive buffer to the USB memory.
Reset
Initialize the setting or counter of the printer.
Profiles
Utilize the printer settings as profiles.
Service
These are the setting items for service.
Strictly for SATO authorized service personnel use.
Factory
These are the setting items for factory.
Strictly for SATO authorized service personnel use.
Certificates
Set the wireless LAN authentication.
◦ Available only if you have installed the USB memory.
Barcode Checker
Set the barcode check function using a barcode checker.
Clone
Copy the current printer settings and data to the USB memory.

SATO CL4NX Specifications

General

Wi-Fi	No
Ethernet LAN	Yes
Flash memory	2000 MB
Storage media	Flash
Internal memory	256 MB
Built-in barcodes	Code 39, Code 93, Code-128 Codabar Library, EAN13, EAN8, GS1 DataBar, Industrial 2/5, Interleaved 2/5, Matrix 2/5
Internal storage capacity	2 GB
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	30 - 90 %
Operating relative humidity (H-H)	30 - 80 %
Maximum roll diameter	220 mm
Maximum printing width	104 mm
Printing media thickness	0.06 - 0.26 µm
Display type	LCD
Product color	Black
Display diagonal	3.5 \
Display resolution	320 x 240 pixels
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	50 - 60 Hz
USB connector	USB Type-A / USB Type-B
Bluetooth version	3.0
Serial interface type	RS-232C
USB 2.0 ports quantity	2
Connectivity technology	Wired & Wireless
Type	POS printer
Print speed	10 ips
Print technology	Direct thermal / Thermal transfer
Maximum resolution	203 x 203 DPI

Weight and Dimensions

Depth	457 mm
Width	271 mm
Height	321 mm
Weight	15000 g
