SATO CL4NX User Manual

External Signal (EXT) Interface
758
Connector Pin Specifications
Pin
No.
I/O Description
16 - LOGIC Ground
17 - Frame Ground
18 - +5 V
19 - STROBE RETURN
20-27 - DATA 1 - DATA 8 RETURN
28 - ACK RETURN
29 - BUSY RETURN
30 - PAPER EMPTY RETURN
31 Input INITIALIZE
32 Output FAULT
33-35 - Not in use
36 Input SELECT INPUT
Cable Specifications
Cable Connector Amphenol 36 pins, male
Cable Length 1.5 m (5 feet) or less
• Specifications are subject to change without notice.
External Signal (EXT) Interface
Basic Specifications of External Signal (EXT) Interface
This interface is designed to connect the printer with other peripherals.
Basic Specifications
Connector Centronics IDC Type 14 pins (Female)
Signal Levels
High-level
+4.2 to +5.0 V

SATO CL4NX Specifications

General

Wi-Fi	No
Ethernet LAN	Yes
Flash memory	2000 MB
Storage media	Flash
Internal memory	256 MB
Built-in barcodes	Code 39, Code 93, Code-128 Codabar Library, EAN13, EAN8, GS1 DataBar, Industrial 2/5, Interleaved 2/5, Matrix 2/5
Internal storage capacity	2 GB
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	30 - 90 %
Operating relative humidity (H-H)	30 - 80 %
Maximum roll diameter	220 mm
Maximum printing width	104 mm
Printing media thickness	0.06 - 0.26 µm
Display type	LCD
Product color	Black
Display diagonal	3.5 \
Display resolution	320 x 240 pixels
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	50 - 60 Hz
USB connector	USB Type-A / USB Type-B
Bluetooth version	3.0
Serial interface type	RS-232C
USB 2.0 ports quantity	2
Connectivity technology	Wired & Wireless
Type	POS printer
Print speed	10 ips
Print technology	Direct thermal / Thermal transfer
Maximum resolution	203 x 203 DPI

Weight and Dimensions

Depth	457 mm
Width	271 mm
Height	321 mm
Weight	15000 g
