SATO CL4NX User Manual

175
• If you use software such as NiceLabel, the settings of the software are enabled, not the
settings of the printer driver.
Printer Driver Sharing Function
Connecting When Using the Printer Driver with Sharing Settings
The figure below shows how to connect when using the printer driver with sharing settings.
Set one computer (PC-0) as the print server and set other computers (PC-1, PC-2, PC-3, and so on)
as clients. All computers should be connected using a LAN connection and the print server and printer
should be connected using LPT, COM, USB, or LAN.
Printer Driver Sharing Settings
The following shows how to set the printer driver when using the printer driver with sharing settings.
1. In both the print server and clients, download and install the printer driver from
the SATO printer driver download site http://www.satoworldwide.com/software/
gallerydriver.aspx.
• If you are adding it with the [Add a printer] icon from the [Printers] folder, the necessary
files may not be installed and may not perform correctly (the copy of the sharing printer
icon on the network computer will be the same).
2. After confirming that a label can be output correctly from the printer driver of the
print server, set the printer driver to "Shared".
3. Specify the output port of the client's printer driver to the sharing printer
configured on the server.
Environment Setting Method
Windows Vista/Server 2008 In the printer driver, open [Properties] > [Ports] > [Add Port]
> [Local Port], and specify the port name as "\\Sharing
computer name\Sharing printer name".
Windows 7/8/8.1/Server 2012 In the printer driver, open [Printer properties] > [Ports] >
[Add Port] > [Local Port], and specify the port name as "\
\Sharing computer name\Sharing printer name".

SATO CL4NX Specifications

General

Wi-Fi	No
Ethernet LAN	Yes
Flash memory	2000 MB
Storage media	Flash
Internal memory	256 MB
Built-in barcodes	Code 39, Code 93, Code-128 Codabar Library, EAN13, EAN8, GS1 DataBar, Industrial 2/5, Interleaved 2/5, Matrix 2/5
Internal storage capacity	2 GB
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	30 - 90 %
Operating relative humidity (H-H)	30 - 80 %
Maximum roll diameter	220 mm
Maximum printing width	104 mm
Printing media thickness	0.06 - 0.26 µm
Display type	LCD
Product color	Black
Display diagonal	3.5 \
Display resolution	320 x 240 pixels
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	50 - 60 Hz
USB connector	USB Type-A / USB Type-B
Bluetooth version	3.0
Serial interface type	RS-232C
USB 2.0 ports quantity	2
Connectivity technology	Wired & Wireless
Type	POS printer
Print speed	10 ips
Print technology	Direct thermal / Thermal transfer
Maximum resolution	203 x 203 DPI

Weight and Dimensions

Depth	457 mm
Width	271 mm
Height	321 mm
Weight	15000 g
