SATO CL4NX User Manual

747
Product Specifications
Printer Specifications
Hardware
Dimensions and Weight
Item CL4NX CL6NX
Width 271 mm (10.67") (Excludes
projection)
338 mm (13.31") (Excludes
projection)
Height 321 mm (12.64") (Excludes
projection)
321 mm (12.64") (Excludes
projection)
Depth 457 mm (18.00") (Excludes
projection)
457 mm (18.00") (Excludes
projection)
Weight Approximately 15.1 kg (33.28
lbs.) (Excludes media, ribbon and
options)
Approximately 20.3 kg (44.75
lbs.) (Excludes media, ribbon and
options)
Power Supply
Item CL4NX CL6NX
Input Voltage AC 100 - 240 V ±10% (Full-range)
Frequency 50 / 60 Hz
Power Consumption
At peak
180 W / 190 VA (Print ratio 30%)
Standby
20 W / 40 VA
At peak
240 W / 308 VA (Print ratio 30%)
Standby
23 W / 63 VA
Processing
Item CL4NX CL6NX
Flash ROM
CPU1
2 GB
CPU2
4 MB

SATO CL4NX Specifications

General

Wi-Fi	No
Ethernet LAN	Yes
Flash memory	2000 MB
Storage media	Flash
Internal memory	256 MB
Built-in barcodes	Code 39, Code 93, Code-128 Codabar Library, EAN13, EAN8, GS1 DataBar, Industrial 2/5, Interleaved 2/5, Matrix 2/5
Internal storage capacity	2 GB
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	30 - 90 %
Operating relative humidity (H-H)	30 - 80 %
Maximum roll diameter	220 mm
Maximum printing width	104 mm
Printing media thickness	0.06 - 0.26 µm
Display type	LCD
Product color	Black
Display diagonal	3.5 \
Display resolution	320 x 240 pixels
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	50 - 60 Hz
USB connector	USB Type-A / USB Type-B
Bluetooth version	3.0
Serial interface type	RS-232C
USB 2.0 ports quantity	2
Connectivity technology	Wired & Wireless
Type	POS printer
Print speed	10 ips
Print technology	Direct thermal / Thermal transfer
Maximum resolution	203 x 203 DPI

Weight and Dimensions

Depth	457 mm
Width	271 mm
Height	321 mm
Weight	15000 g
