SATO CL4NX User Manual

67
Powering On/Off the Printer
Connecting the Power Cord
• Do not touch the power button, connect or disconnect the power cord while your hands
are wet. Doing so could cause an electric shock.
• Always connect the ground wire to a ground terminal. Electric shock could occur if you
do not.
• Make sure that the AC voltage of your region is in the range of AC 100 - 240 V, 50 -
60 Hz. If your local voltage is not in the stated range, contact your SATO reseller or
technical support center.
• The attached power cord is designed exclusively for this printer. Do not use it with
other devices.
1. Connect the power cord to the AC input terminal (1) at the rear of the printer.
Take note of the orientation of the connector. Secure the printer with one hand, and insert the
connector tightly.
2. Insert the power plug into an AC outlet.
* The shape of the power plug varies depending on the region in which it was purchased.

SATO CL4NX Specifications

General

Wi-Fi	No
Ethernet LAN	Yes
Flash memory	2000 MB
Storage media	Flash
Internal memory	256 MB
Built-in barcodes	Code 39, Code 93, Code-128 Codabar Library, EAN13, EAN8, GS1 DataBar, Industrial 2/5, Interleaved 2/5, Matrix 2/5
Internal storage capacity	2 GB
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	30 - 90 %
Operating relative humidity (H-H)	30 - 80 %
Maximum roll diameter	220 mm
Maximum printing width	104 mm
Printing media thickness	0.06 - 0.26 µm
Display type	LCD
Product color	Black
Display diagonal	3.5 \
Display resolution	320 x 240 pixels
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	50 - 60 Hz
USB connector	USB Type-A / USB Type-B
Bluetooth version	3.0
Serial interface type	RS-232C
USB 2.0 ports quantity	2
Connectivity technology	Wired & Wireless
Type	POS printer
Print speed	10 ips
Print technology	Direct thermal / Thermal transfer
Maximum resolution	203 x 203 DPI

Weight and Dimensions

Depth	457 mm
Width	271 mm
Height	321 mm
Weight	15000 g
