SATO CL4NX User Manual

Optional Devices
26
Optional Devices
The optional devices for the printer are as follows. The optional devices can be factory installed or
installed by the customer engineer. Contact your SATO reseller or technical support center.
Supported ModelsOptional Devices Description
CL4NX CL6NX
Cutter unit Automatically cuts the media in
the designated number of pages.
Available Available
Simple dispenser kit Removes the label from the liner.
The liner is ejected out of the
printer.
Available Available
Dispenser unit (with internal liner
rewinder)
Removes the label from the liner.
The liner can be ejected out of
the printer or rewound inside of
the printer.
Available Available
Linerless cutter kit The environmentally friendly
linerless labels can be used.
Available -
RTC (Calendar) kit A calendar system for printing
the date and time on a label to
output.
Available Available
External rewinder Automatically rewinds the label
output by the printer.
Available
RWG500
Available
RWG500
(6-inch
extension
kit)
UHF RFID kit
(ISO/IEC 18000-6 Type C Gen2)
Supports UHF RFID. It can read
and write to the IC tag and label.
Available -
HF RFID kit
(ISO/IEC15693, ISO/IEC 14443
TypeA, FeliCa Lite-S)
Supports HF RFID. It can read
and write to the IC tag and label.
Available -
WLAN 802.11a/b/g/n Dual Band
WLAN (2.4GHz, 5GHz)
Communicates with the wireless
LAN.
Available Available
Barcode checker stand kit A stand kit to mount the barcode
checker.
Available Available
External cover kit A set of covers to prevent dust
from entering the external
openings for label supply.
Available Available

SATO CL4NX Specifications

General

Wi-Fi	No
Ethernet LAN	Yes
Flash memory	2000 MB
Storage media	Flash
Internal memory	256 MB
Built-in barcodes	Code 39, Code 93, Code-128 Codabar Library, EAN13, EAN8, GS1 DataBar, Industrial 2/5, Interleaved 2/5, Matrix 2/5
Internal storage capacity	2 GB
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	30 - 90 %
Operating relative humidity (H-H)	30 - 80 %
Maximum roll diameter	220 mm
Maximum printing width	104 mm
Printing media thickness	0.06 - 0.26 µm
Display type	LCD
Product color	Black
Display diagonal	3.5 \
Display resolution	320 x 240 pixels
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	50 - 60 Hz
USB connector	USB Type-A / USB Type-B
Bluetooth version	3.0
Serial interface type	RS-232C
USB 2.0 ports quantity	2
Connectivity technology	Wired & Wireless
Type	POS printer
Print speed	10 ips
Print technology	Direct thermal / Thermal transfer
Maximum resolution	203 x 203 DPI

Weight and Dimensions

Depth	457 mm
Width	271 mm
Height	321 mm
Weight	15000 g
