SATO CL4NX User Manual

[Print Mode]
226
When using [Auto-mode], the print mode changes automatically according to the status of the installed
option unit.
The options are as follows:
Enabled
The print mode changes automatically.
Disabled
The print mode changes according to the setting of the [Print Mode].
• Operate in cutter mode if you have installed the optional cutter unit.
• Operate in dispenser mode if you have installed the optional dispenser unit.
• Operate in linerless mode if you have installed the optional linerless cutter kit (CL4NX
only).
[Print Mode]
Set the print mode.
The options are as follows:
Continuous
Continuously print the specified number of the media. The media remains in position for printing at
all times.
Tear-Off
After continuously printing the specified number of the media, feed the media to the point to
remove the media. After printing, tear off the media manually. The media will be back to the print
head position for starting the next printing.
Cutter
Cut each media while printing the specified number of media. You can specify this option only if
you have installed the cutter unit.
Cut & Print
Allows you to continuously print and cut at the specified media repeat. If no print data is received
within the period specified for [Eject Cut], the printer will feed the media to the cut position and cut
the last printed media. You can specify this option only if you have installed the cutter unit.

SATO CL4NX Specifications

General

Wi-Fi	No
Ethernet LAN	Yes
Flash memory	2000 MB
Storage media	Flash
Internal memory	256 MB
Built-in barcodes	Code 39, Code 93, Code-128 Codabar Library, EAN13, EAN8, GS1 DataBar, Industrial 2/5, Interleaved 2/5, Matrix 2/5
Internal storage capacity	2 GB
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	30 - 90 %
Operating relative humidity (H-H)	30 - 80 %
Maximum roll diameter	220 mm
Maximum printing width	104 mm
Printing media thickness	0.06 - 0.26 µm
Display type	LCD
Product color	Black
Display diagonal	3.5 \
Display resolution	320 x 240 pixels
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	50 - 60 Hz
USB connector	USB Type-A / USB Type-B
Bluetooth version	3.0
Serial interface type	RS-232C
USB 2.0 ports quantity	2
Connectivity technology	Wired & Wireless
Type	POS printer
Print speed	10 ips
Print technology	Direct thermal / Thermal transfer
Maximum resolution	203 x 203 DPI

Weight and Dimensions

Depth	457 mm
Width	271 mm
Height	321 mm
Weight	15000 g
