SATO CL4NX User Manual

221
Resolution CL4NX CL6NX
(1 dot = 0.042 mm
(0.0017"))
• Set the label size to a value that includes the liner.
[Label Width]
Set the width of the media.
The setting range varies depending on the print resolution of the printer.
The setting range of the label width is as follows:
Resolution CL4NX CL6NX
If [Head Base Position]
is [Standard]
CL6NX
If [Head Base Position]
is [Left-justify]
203 dpi
(1 dot =
0.125 mm
(0.0049"))
1 to 832 dots 1 to 1216 dots 1 to 1340 dots
305 dpi
(1 dot =
0.083 mm
(0.0033"))
1 to 1248 dots 1 to 1984 dots 1 to 2010 dots
609 dpi
(1 dot =
0.042 mm
(0.0017"))
1 to 2496 dots - -
• Set the label size to a value that includes the liner.

SATO CL4NX Specifications

General

Wi-Fi	No
Ethernet LAN	Yes
Flash memory	2000 MB
Storage media	Flash
Internal memory	256 MB
Built-in barcodes	Code 39, Code 93, Code-128 Codabar Library, EAN13, EAN8, GS1 DataBar, Industrial 2/5, Interleaved 2/5, Matrix 2/5
Internal storage capacity	2 GB
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	30 - 90 %
Operating relative humidity (H-H)	30 - 80 %
Maximum roll diameter	220 mm
Maximum printing width	104 mm
Printing media thickness	0.06 - 0.26 µm
Display type	LCD
Product color	Black
Display diagonal	3.5 \
Display resolution	320 x 240 pixels
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	50 - 60 Hz
USB connector	USB Type-A / USB Type-B
Bluetooth version	3.0
Serial interface type	RS-232C
USB 2.0 ports quantity	2
Connectivity technology	Wired & Wireless
Type	POS printer
Print speed	10 ips
Print technology	Direct thermal / Thermal transfer
Maximum resolution	203 x 203 DPI

Weight and Dimensions

Depth	457 mm
Width	271 mm
Height	321 mm
Weight	15000 g
