SATO CL4NX User Manual

625
Configuring Optional Barcode Check Function
Basic Specifications of the Barcode Check Function
The barcode check function does a reading check of a barcode printed by this printer to prevent the
distribution of labels with defective barcodes. You can use this function by installing the supported
barcode checkers to the printer.
The basic specifications of the barcode check function are as follows:
Item Specification
Supported Barcode
Checkers
• IDEC/DATALOGIC WB1F-100S1S (for 1D barcodes, USB
connection)
• IDEC/DATALOGIC GFS4470 (for 1D barcodes/2D codes, USB
connection)
• KEYENCE BL-1301 (for 1D barcodes, RS-232C connection)
• KEYENCE SR-710 (for 1D barcodes/2D codes, RS-232C
connection)
Refer to the manual of the barcode checker for its settings and
supported barcodes.
Supported Commands SBPL/SZPL/SIPL/STCL/SDPL/SEPL
• AEP is not supported.
Supported Print Modes Continuous/Cutter/Cut & Print/Dispenser/Linerless (CL4NX only)
• Not available in Tear-Off mode.
• Not available for CL4NX RFID models.
• The Void Print function is not available in Dispenser/
Linerless (CL4NX only) mode.
Print Speed/Print
Darkness
The optimal print speed and print darkness for secure reading vary
depending on various conditions, such as the barcode type and label
layout. Be sure to perform a test read carefully and determine the
settings.
Printable Area
(Barcode Readable Area)
Same as the printer specifications. However, there are following
restrictions:

SATO CL4NX Specifications

General

Wi-Fi	No
Ethernet LAN	Yes
Flash memory	2000 MB
Storage media	Flash
Internal memory	256 MB
Built-in barcodes	Code 39, Code 93, Code-128 Codabar Library, EAN13, EAN8, GS1 DataBar, Industrial 2/5, Interleaved 2/5, Matrix 2/5
Internal storage capacity	2 GB
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	30 - 90 %
Operating relative humidity (H-H)	30 - 80 %
Maximum roll diameter	220 mm
Maximum printing width	104 mm
Printing media thickness	0.06 - 0.26 µm
Display type	LCD
Product color	Black
Display diagonal	3.5 \
Display resolution	320 x 240 pixels
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	50 - 60 Hz
USB connector	USB Type-A / USB Type-B
Bluetooth version	3.0
Serial interface type	RS-232C
USB 2.0 ports quantity	2
Connectivity technology	Wired & Wireless
Type	POS printer
Print speed	10 ips
Print technology	Direct thermal / Thermal transfer
Maximum resolution	203 x 203 DPI

Weight and Dimensions

Depth	457 mm
Width	271 mm
Height	321 mm
Weight	15000 g
