SATO CL4NX User Manual

53
•
To exit the Settings mode, press the button.
Logging In to/Logging Out of the Settings Mode
The Settings mode logs in and logs out by the following procedure, if the password is enabled.
• If the password is enabled, input the password after entering the Settings mode.
When logged in to the Settings mode, [LOG OUT] appears on the bottom left of the screen.
•
Press the button to log out of the Settings mode.
Password is required to enter the Settings mode again.
• With password enabled, if no button is pressed for about 10 minutes after login, the
login session will end automatically. Password is required to enter the Settings mode
again.
Item Selection
Select an item in Settings mode according to the following procedure:

SATO CL4NX Specifications

General

Wi-Fi	No
Ethernet LAN	Yes
Flash memory	2000 MB
Storage media	Flash
Internal memory	256 MB
Built-in barcodes	Code 39, Code 93, Code-128 Codabar Library, EAN13, EAN8, GS1 DataBar, Industrial 2/5, Interleaved 2/5, Matrix 2/5
Internal storage capacity	2 GB
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	30 - 90 %
Operating relative humidity (H-H)	30 - 80 %
Maximum roll diameter	220 mm
Maximum printing width	104 mm
Printing media thickness	0.06 - 0.26 µm
Display type	LCD
Product color	Black
Display diagonal	3.5 \
Display resolution	320 x 240 pixels
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	50 - 60 Hz
USB connector	USB Type-A / USB Type-B
Bluetooth version	3.0
Serial interface type	RS-232C
USB 2.0 ports quantity	2
Connectivity technology	Wired & Wireless
Type	POS printer
Print speed	10 ips
Print technology	Direct thermal / Thermal transfer
Maximum resolution	203 x 203 DPI

Weight and Dimensions

Depth	457 mm
Width	271 mm
Height	321 mm
Weight	15000 g
