SATO CL4NX User Manual

489
Excl. LAN/Wi-Fi/IP
Copy the printer settings and data, excluding network information, to the USB memory. This is
useful when you set up multiple printers already configured for network with the same printer
settings.
Incl. LAN/Wi-Fi
Copy the printer settings and data, including network information (excluding the IP address), to
the USB memory. This is useful when you set up multiple printers to be connected to the same
network with the same printer settings.
Incl. LAN/Wi-Fi/IP
Copy the printer settings and data, including network information (with the IP address), to the USB
memory. This is useful when carrying the settings of the printer to be replaced to a new printer.
[Startup Guide]
Enable or disable the startup guide.
The options are as follows:
Enabled
Enable the startup guide.
Disabled
Disable the startup guide.
If you have selected [Enabled], the startup guide appears when you power on the printer.

SATO CL4NX Specifications

General

Wi-Fi	No
Ethernet LAN	Yes
Flash memory	2000 MB
Storage media	Flash
Internal memory	256 MB
Built-in barcodes	Code 39, Code 93, Code-128 Codabar Library, EAN13, EAN8, GS1 DataBar, Industrial 2/5, Interleaved 2/5, Matrix 2/5
Internal storage capacity	2 GB
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	30 - 90 %
Operating relative humidity (H-H)	30 - 80 %
Maximum roll diameter	220 mm
Maximum printing width	104 mm
Printing media thickness	0.06 - 0.26 µm
Display type	LCD
Product color	Black
Display diagonal	3.5 \
Display resolution	320 x 240 pixels
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	50 - 60 Hz
USB connector	USB Type-A / USB Type-B
Bluetooth version	3.0
Serial interface type	RS-232C
USB 2.0 ports quantity	2
Connectivity technology	Wired & Wireless
Type	POS printer
Print speed	10 ips
Print technology	Direct thermal / Thermal transfer
Maximum resolution	203 x 203 DPI

Weight and Dimensions

Depth	457 mm
Width	271 mm
Height	321 mm
Weight	15000 g
