SATO CL4NX User Manual

177
All-In-One Tool Features
When you add the printer to the All-In-One Tool, you can easily set and manage the printer.
The main functions of the All-In-One Tool are as follows:
• For details of the All-In-One Tool, download and read the All-In-One Tool Manual from
the SATO All-In-One Tool download site http://www.satoworldwide.com/software/all-in-
one-tool.aspx.
(1) Print and interface settings can be configured from the [Configuration] panel displayed when
selecting the printer on the main screen.
(2) Application settings and status monitoring of the printer can be enabled from the menu displayed
when right-clicking after selecting the printer on the main screen.
(3) Fonts and graphics can be stored in the printer and the SBPL command can be sent from the
[Tools] menu of the main screen.

SATO CL4NX Specifications

General

Wi-Fi	No
Ethernet LAN	Yes
Flash memory	2000 MB
Storage media	Flash
Internal memory	256 MB
Built-in barcodes	Code 39, Code 93, Code-128 Codabar Library, EAN13, EAN8, GS1 DataBar, Industrial 2/5, Interleaved 2/5, Matrix 2/5
Internal storage capacity	2 GB
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	30 - 90 %
Operating relative humidity (H-H)	30 - 80 %
Maximum roll diameter	220 mm
Maximum printing width	104 mm
Printing media thickness	0.06 - 0.26 µm
Display type	LCD
Product color	Black
Display diagonal	3.5 \
Display resolution	320 x 240 pixels
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	50 - 60 Hz
USB connector	USB Type-A / USB Type-B
Bluetooth version	3.0
Serial interface type	RS-232C
USB 2.0 ports quantity	2
Connectivity technology	Wired & Wireless
Type	POS printer
Print speed	10 ips
Print technology	Direct thermal / Thermal transfer
Maximum resolution	203 x 203 DPI

Weight and Dimensions

Depth	457 mm
Width	271 mm
Height	321 mm
Weight	15000 g
