Description of the blocks
4.3 MMOprtn block
SIMOCODE pro PCS 7 Library V9.0
Programming and Operating Manual, 06/2017, A5E40899442002A/RS-AA/001
109
Phase 2: Hardware test result
● If there is a fault, HW fault basic unit is triggered.
● If there is no fault:
– The "GEN. FAULT" LED flashes when no main current is flowing.
– The "GEN. FAULT" LED flickers if main current is flowing (in all three phases)
● Contactor controls remain unchanged.
4.3.10
Trip reset
SIMOCODE can be reset with the trip reset command in the following situations:
● The cause of the fault has been eliminated.
● No ON control command is pending.
●
RdytoReset is generated in the previous APL or at the MMRevDhl block
This resets the process image output PIO DP 0.6.
Reset trip
A trip can be reset as follows:
Table 4- 18 Trip reset
Operating mode
Parameter
Value
Meaning
Assigned PIO bits
AUTO /
MANUAL
TrpRstLi
1 Trip reset active, trip is reset. DP 0.6 = 1
AUTO /
MANUAL
TrpRstOp
1, 2
1 Trip reset active, trip is reset. DP 0.6 = 1
1
The command is reset at the end of the execution cycle of the block.
2
If the operation has been enabled in the Standard view (OS_Perm = 1).
4.3.11
Group fault
The output parameter for group error GrpErr is set when one of the errors listed below is
detected. The Standard view displays these errors as a group error in plain text.
● General Fault (GenFlt) of the SIMOCODE
● Module Fault
● Rack Fault
