Siemens SIMOCODE pro User Manual

Description of the blocks
4.5 Block for statistical function MMStat
SIMOCODE pro PCS 7 Library V9.0
176 Programming and Operating Manual, 06/2017, A5E40899442002A/RS-AA/001
Message block MsgEvId1
Table 4- 77 Output messages
Message block
Message No.
Block parameters
Message text
Message
class *
MsgEvId1
1
ExtMsg1 **
$$BlockComment$$External message 1
S
2
ExtMsg2
** $$BlockComment$$External message 2 S
3
ExtMsg3 **
$$BlockComment$$External message 3
S
4
ExtMsg4 **
$$BlockComment$$External message 4
S
5
ExtMsg5 **
$$BlockComment$$External message 5
S
6
ExtMsg6 **
$$BlockComment$$External message 6
S
7
ExtMsg7 **
$$BlockComment$$External message 7
S
8
ExtMsg8 **
$$BlockComment$$External message 8
S
* S = AS, OS process control fault
** User-definable message
Auxiliary values
The block supports 10 programmable auxiliary values.
Table 4- 78 Structure of the auxiliary values ALARM_8P
Message
No.
Auxiliary value
Block parameters
Meaning
1
1
BatchName
Name of batch
2
2
StepNo
Step number
3
3
BatchID
Identification number of the batch
4
4
ExtVa104
External value 4, user-definable
5
5
ExtVa105
External value 5, user-definable
6
6
ExtVa106
External value 6, user-definable
7
7
ExtVa107
External value 7, user-definable
8
8
ExtVa108
External value 8, user-definable
9
9
ExtVa109
External value 9, user-definable
10
10
ExtVa110
External value 10, user-definable
The MsgStat1, MsgAckn1, and MsgErr1 parameters transfer the following information:
● Message status
● Message error
● Message acknowledgment status
4.5.6
Start-up characteristics
The alarm messages are suppressed in the OB100 for the RunUpCyc no. of times.
