Description of the blocks
4.4 Block for MMMeas measured value function
SIMOCODE pro PCS 7 Library V9.0
Programming and Operating Manual, 06/2017, A5E40899442002A/RS-AA/001
167
Current values
①
Current values as bars (Curr_OpScale high value, low value)
②
Phase current in % le (CurrL1, CurrL2, CurrL3)
③
Maximum motor current in % le (ImMax)
④
Last trip current in % le (TripCurr)
⑤
Phase unbalance in % (PhaUnbal)
Thermal motor model
⑥
Ther
mal memory in % (ThmMotMod)
⑦
Remaining motor cooling
-down period (MotColTm)
⑧
Remaining time to trip (Triptime)
⑨
Last successfull Timestamp of Read Data
⑩
Button for updating the data (RdDataOp).
Button is deactivated if RackF_Act = 1, authorization level 5 and higher
(ProcessControling)
These parameters are enabled when a current measuring module is connected.
4.4.9.3
MMMeas - Standard 2
Standard 2 view
Module Type
Availability
Button Status
Operation Control
Voltage Module Yes Enabled
No Disabled
