Siemens SIMOCODE pro User Manual

Description of the blocks
4.5 Block for statistical function MMStat
SIMOCODE pro PCS 7 Library V9.0
Programming and Operating Manual, 06/2017, A5E40899442002A/RS-AA/001
173
4.5.2
Parameterizable functions via the Feature connection MMStat
The modules of the library have an input named Feature. You can influence various
responses of the block via this input.
The Feature Bits are assigned in the following order:
Table 4- 73 Meaning of Feature.Bits
Feature.Bit
Meaning
Feature.Bit1
Response for Out of Service mode (Page 81)
Feature.Bit10 1 = Suppress External Message 1 (Page 91)
Feature.Bit11
1 = Suppress External Message 1 (Page 91)
Feature.Bit12 1 = Suppress External Message 1 (Page 91)
Feature.Bit13
1 = Suppress External Message 1 (Page 91)
Feature.Bit14
1 = Suppress External Message 1 (Page 91)
Feature.Bit15
1 = Suppress External Message 1 (Page 91)
Feature.Bit16
1 = Suppress External Message 1 (Page 91)
Feature.Bit17
1 = Suppress External Message 1 (Page 91)
Feature.Bit22
Update acknowledgment and error status of the alarm call (Page 87)
Feature.Bit24
Activate local operator permission (Page 87)
Feature.Bit25
Suppression of all messages (Page 88)
The default setting is 0 in each case.
4.5.3
Operating modes
The following operating modes are displayed on the block:
● Local
● ON
● Out of service (Oos)
4.5.4
Statistical values
The MMStat block reads statistical information via the DS95 data record.
Table 4- 74 DS95
No.
Data record num-
ber
Read access/write
access
Number of
bytes
Description
1
DS95
R
90
Read statistical values
The DS95 data record is based on the read capability. The values are read from the
SIMOCODE pro device with the "RDREC" function. This information is written to the output
parameters.
