Siemens SIMOCODE pro User Manual

Description of the blocks
4.4 Block for MMMeas measured value function
SIMOCODE pro PCS 7 Library V9.0
Programming and Operating Manual, 06/2017, A5E40899442002A/RS-AA/001
161
4.4.5
Message characteristics
MMMeas reports the following errors at the block output:
● Rack fault (
RackF_Act)
● Module fault (
ModF_Act)
An error generates a group error
GrpErr in output parameter Err_Act.
These errors are not signaled as alarms as they are already part of the MMDiag block (both
on the DP master system and behind the Y-Link/ IE-PB-Link). The alarms are output using
the ALARM_8P function.
The messages can be enabled or disabled using the
MsgLock input.
The alarms are also suppressed if the block is in Out of service mode.
The alarms are suppressed on warm restart for the number of cycles set for power up in the
RunUpCyc parameter.
Message block MsgEvId1
Table 4- 69 Output messages
Message block
Message No.
Block parameters
Message text
Message
class *
MsgEvId1
1
ExtMsg1 **
$$BlockComment$$External Message 1
S
2
ExtMsg2
** $$BlockComment$$External message 2 S
3
ExtMsg3 **
$$BlockComment$$External message 3
S
4
ExtMsg4 **
$$BlockComment$$External message 4
S
5
ExtMsg5 **
$$BlockComment$$External message 5
S
6
ExtMsg6 **
$$BlockComment$$External message 6
S
7
ExtMsg7 **
$$BlockComment$$External message 7
S
8
ExtMsg8 **
$$BlockComment$$External message 8
S
* S = AS, OS process control fault
** User-definable message
