Siemens SIMOCODE pro User Manual

Parameter
A.3 Block parameter MMOprtn
SIMOCODE pro PCS 7 Library V9.0
250 Programming and Operating Manual, 06/2017, A5E40899442002A/RS-AA/001
Parameter
Data format
Default setting
Meaning
ManAct STRUCT
• Value: BOOL
• ST: BYTE
–
• 1
• 16#80
Manual value is active
IntlAct STRUCT
• Value: BOOL
• ST: BYTE
–
• 0
• 16#80
Interlocking time active
ChgOvrAct STRUCT
• Value: BOOL
• ST: BYTE
–
• 0
• 16#80
Change-over pause active
GenFlt STRUCT
• Value: BOOL
• ST: BYTE
–
• 0
• 16#00
General fault
GenWarn STRUCT
• Value: BOOL
• ST: BYTE
–
• 0
• 16#00
General warning
CSFlt STRUCT
• Value: BOOL
• ST: BYTE
–
• 0
• 16#80
1 = Control system fault active (CSF)
CurWrnH STRUCT
• Value: BOOL
• ST: BYTE
–
• 0
• 16#80
1 = Current warn high is active
CurWrnL STRUCT
• Value: BOOL
• ST: BYTE
–
• 0
• 16#80
1 = Current warn low is active
CurTrpH STRUCT
• Value: BOOL
• ST: BYTE
–
• 0
• 16#80
1 = Current trip high is active
CurTrpL STRUCT
• Value: BOOL
• ST: BYTE
–
• 0
• 16#80
1 = Current trip low is active
TPF STRUCT
• Value: BOOL
• ST: BYTE
–
• 0
• 16#80
1 = Test position feedback on (TPF)
PreWrnOvl STRUCT
• Value: BOOL
• ST: BYTE
–
• 0
• 16#80
1 = Prewarning overload
