Siemens SIMOCODE pro User Manual

Parameter
A.4 Block parameter MMMeas
SIMOCODE pro PCS 7 Library V9.0
254 Programming and Operating Manual, 06/2017, A5E40899442002A/RS-AA/001
Parameter
Data format
Default setting
Meaning
OosOp BOOL FALSE 1 = Out of Service mode:
Out of Service mode by operator
OosLi STRUCT
• Value: BOOL
• ST: BYTE
–
• 0
• 16#80
1 = Out of Service mode:
Out of Service mode via field signal
Curr_OpScale STRUCT
• HIGH: REAL
• LOW: REAL
–
• 1020.0
• 0.0
Current - Bar Display Limits for OS
Vol_OpScale STRUCT
• HIGH: REAL
• LOW: BYTE
–
• 2040.0
• 0.0
Voltage - Bar Display Limits for OS
Ana_OpScale STRUCT
• HIGH: REAL
• LOW: BYTE
–
• 118.5
• 0.0
Analog Output/Input - Bar Display Limits for OS
SampleTime
REAL
0.1
Sampling Time [s]
RunUpCyc
INT
3
Number of cycles for which all messages are suppressed
MsgEvId1
DWORD
16#FF
Message Event ID 1
MsgLock STRUCT
• Value: BOOL
• ST: BYTE
–
• 0
• 16#80
Inhibit process message
ExtMsg1 STRUCT
• Value: BOOL
• ST: BYTE
–
• 0
• 16#80
External message 1
ExtMsg2 STRUCT
• Value: BOOL
• ST: BYTE
–
• 0
• 16#80
External message 2
ExtMsg3 STRUCT
• Value: BOOL
• ST: BYTE
–
• 0
• 16#80
External message 3
ExtMsg4 STRUCT
• Value: BOOL
• ST: BYTE
–
• 0
• 16#80
External message 4
ExtMsg5 STRUCT
• Value: BOOL
• ST: BYTE
–
• 0
• 16#80
External message 5
ExtMsg6 STRUCT
• Value: BOOL
• ST: BYTE
–
• 0
• 16#80
External message 6
