Parameterizing machine data
3.2 Parameterizing the control using machine data
HMI Advanced (IM4)
Commissioning Manual, 03/2009, 6FC5397-0DP10-3BA0
103
Entry in the file NCTEA_GR.TXT:
3
14510[0] My integer text for PLC-MD 14510.0
14514[0] Text for float data 14514.0
14516[2] This is the text in HEX for MD14516.2
result in the display:
14510[0] My integer text for PLC-MD 14510.0
14514[0] Text for float data 14514.0
14516[2] This is the text in HEX for MD14516.2
Note
PLC machine data texts are created and handled in the same way as alarm texts.
Language code for the text files according to the Table: "Languages and ANSI tables / code
page used".
See also
Classifying user alarms (Page 83)
3.2.6 Set tool offset to be active immediately
Function
Wit the display MD 9440: ACTIVATE_SEL_USER_DATA can be used to specify that
changes in the tool offsets are activated immediately even if the NC channel is not in "Reset"
or "Stop" state. This function is always active.
CAUTION
The offset is applied after NC Start of the Reset in response to the next programmed axis
movement in the part program.
References: Function Manual Basic Functions: Axes, coordinate systems, frames (K2)
