Alarm/Machine data help
2.2 Alarm help
Online Help (HE1)
30 Commissioning Manual, 11/2006, 6FC5397-0DP10-0BA0
2) Generate text file
Copy the single-column index generated above (right-justified page numbers) and save it in
a TXT file.
Example:
10702 90
<ID> <page>
The search string (alarm number) is identical to the ID number in this case.
The text file for the PDF call now requires the following syntax:
<PDF file name> <ID> <page>
Enter the name of the PDF file at the start of each line.
Example:
ALARM.PDF 10702 90
ALARM.PDF 10703 90
ALARM.PDF 10704 91
<PDF name> <ID> <page>
3) Generate PDF file
Print your document as a postscript file and convert this to PDF format using Adobe Acrobat
Distiller.
4) Read files into controller
The generated files (*.PDF and *.TXT) must now be read into the controller, e.g., into
directory F:\DH\USER\HLP.
2.2.3 User comments on help
Function
The alarm help ([i] key in diagnostics) provides the "Notepad" function for entering user-
specific texts for individual alarms. These texts are stored in directory:
F:\USER\RH
Note
Alarm-specific texts can be stored if the HMI help is called up using the [i] key from the alarm
overview or from the alarm log for the corresponding alarm.
This is not possible when the alarm is selected from the table of contents.
