Siemens SINUMERIK Commissioning Manual

Configure hotkeys and PLC keys
4.5 List of selectable states
Expanding the user interface
4-24 Commissioning Manual, 11/2006, 6FC5397-0DP10-0BA0
State Function
660 – /user screen form
680 User data
690 Machine data
4.5.4 Selectable states in ShopTurn on NCU
Machine manual (without "Machine manual" option)
Legend:
* If option available (display MD is set)
Custom screen These designated functions can be configured with the "Expanding the
Operator Interface" system.
If this type of configuration is available, it is activated. Otherwise, the
standard ShopMill screen will appear.
State Function
19 Main screen
2 T, S, M, etc.
30 Workpiece zero
31 Workpiece zero – /user screen form
34 Workpiece zero – /user screen form
35 Workpiece zero – /user screen form
36 Workpiece zero – /user screen form
37 Workpiece zero – /user screen form
38 Workpiece zero – /user screen form
40 Workpiece zero – /user screen form
5 Workpiece zero – measure edge Z
50 Measure tool
51 Measure tool – length manual X/user screen form
52 Measure tool – length manual Z/user screen form
53 Measure tool – zoom*/user screen form
54 Measure tool – /user screen form
55 Measure tool – /user screen form
56 Measure tool – calibration probe*/user screen form
57 Measure tool – /user screen form
58 Measure tool – automatic Z *
59 Measure tool – automatic X *
4 Position
18 Face milling*
80 Cutting*
