HMI Advanced (IM4)
Commissioning Manual, 03/2009, 6FC5397-0DP10-3BA0
91
Parameterizing machine data
3
3.1 Handling machine data via the HMI
Overview
Specific settings can be made to address manufacturer manufacturer and user requirements
by:
● Configuring the HMI operator interface using INI files
● Parameterizing the control using machine data
● Programming PLC Functions
DANGER
Changes in the machine data have a considerable influence on the machine. Incorrect
configuration of the parameters can endanger human life and cause damage to the
machine.
Requirements
Access to the machine data operating area can be controlled by key-operated switch or
password.
Classification of machine data
The machine data is divided into the following areas:
● General machine data ($MN )
● Channel-specific machine data ($MC )
● Axis-specific machine data ($MA )
● Display machine data ($MM )
● Drive-specific machine data ($M_)
● Machine data control unit: Drive parameters (solution line)
● Infeed-machine data: Drive parameters (solution line)
A separate list display is provided for each of these areas in which you can view and edit
machine data.
The following properties of the machine data are displayed from left to right:
● Machine data number
● Machine data name, with field index if applicable.
● Value of the machine data
