Commissioning a system
1.1 Delivery condition of the system
PCU-Basesoftware (IM8)
Commissioning Manual, 03/2009, 6FC5397-1DP10-4BA0
7
Content of the partitions
The individual partitions are intended for the following data or already contain this data:
EMERGENCY (C:) Reserved for service tasks under WinPE 2005.
TMP (D:) Used for storing ghost images (e.g. of the status on delivery) and
local backup images.
Contains the installation directory where the software to be installed
is first copied to from a remote PG/PC prior to the actual installation
procedure.
SYSTEM (E:) Reserved for the Windows XP software.
The Windows XP software is available on the recovery media CD via
network, for example to install drivers or updates as and when
needed later on.
USER (F:) For installing user programs.
Applications such as HMI system software (incl. data storage and
temporary data), STEP7, OEM applications for HMI or customer-
specific applications should only be installed here.
NOTICE
All of the applications must be exclusively installed on USER (F:); even if these applications
have a different drive set as the default drive in their installation path.
The partition names EMERGENCY, TMP, SYSTEM, USER must not be changed;
otherwise the "ServiceCenter" will no longer function.
See also
Installing SINUMERIK products (Page 53)
Starting ServiceCenter Backup Restore (Page 63)
1.1.2 System features
Configuration of the operating system
For safety reasons, Windows XP has been preset as follows:
● The Autorun function is deactivated.
● Automatic Windows Update is deactivated.
● Monitoring and alerts for antivirus software and automatic update are deactivated.
● Links used to call up Internet Explorer from the service desktop and the start menu are
removed.
● Remote Procedure Call (RPC) is possible for calls that are not connected.
● The firewall settings are activated on the network card Eth 1 and deactivated on Eth 2.
