Parameterizing machine data
3.2 Parameterizing the control using machine data
HMI Advanced (IM4)
104 Commissioning Manual, 03/2009, 6FC5397-0DP10-3BA0
3.2.7 Hiding axes
Function
Via the channel-specific MD 20098: DISPLAY_AXIS to suppress the display of the axes in
the Machine area. All axes are displayed by default.
Axes can be hidden in the following windows in the Machine operating area.
● Small axis window (5 axes, default setting for machine)
● Wide axis window (5 axes with feed and override)
● Large axis window (8 axes, large font)
In this way you can specify separately for the view in the machine or workpiece coordinate
system whether or not the axis is displayed:
Bits 0 to 15: Display (=1)/hide (=0) geometry axes (WCS)
Bits 16 to 31: Display (=1)/hide (=0) machine axes (MCS)
Reference point approach and Safety Integrated (special cases)
Machine data 20098: DISPLAY_AXIS is not used for the displays in the referencing
operating mode, namely the "Axes Reference Point and Acknowledge Safe Position" display.
All machine axes are always displayed.
The operator cannot change the values for the basic work offset without the appropriate
access authorization.
Access authorization 7 is entered as the default value in MD 9247 and MD 9248.
20098 DISPLAY_AXIS
MD number Display or hide axis on the HMI
Default setting: 0xFFFFFFFF Min. input limit: 0 Maximum input limit: 0xFFFFFFFF
Changes effective after POWER ON Protection level: 2/7 Units: -
Data type: DWORD Applies from SW version: 4.4
Significance: ID as to whether the axis should be displayed as machine, geometry or help axis.
Bits 0 to 15: WCS Bit 0 = 1
= 0
Display geometry axis in actual-value windows
Hide geometry axis in actual-value windows
Bit 1 = 1
= 0
Display geometry axis in reference point windows
Hide geometry axis in the reference point windows
Bit 2 = 1
= 0
Display geometry axis in n preset / basis offset / scratching window
Hide geometry axis in preset / basis offset / scratching window
Bit 3 = 1
= 0
Display geometry axis in handwheel selection window
Hide geometry axis in handwheel selection window
