Tool management
6.2 Settings in the configuration file
HMI Advanced (IM4)
Commissioning Manual, 03/2009, 6FC5397-0DP10-3BA0
187
● If adapter data is set in the NCK, the magazine list can be displayed either transformed or
not transformed (softkey on the ETC bar). The setting is made in paramtm.ini, section
[TMMODES], with the entry START_MAGLIST_TRANSFORMED
● Suppression of status bits for tool cabinet, code carrier, SINCOM excerpt from
paramtm.ini:
– ;Tool status:
If a tool is removed from the NCK and transferred to an external medium (tool cabinet,
code carrier, SINCOM), you can use the following screens to specify which tool status
bits should be saved.
– ;Code carrier:
Since the standard conversion file wkonvert.txt has entered 1 byte for the tool status
and a max. of 92 have been written to the code carrier up to now,
CODECARRIER_TOOLSTATE_MASK receives the default value 92. If the value for
CODECARRIER_TOOLSTATE_MASK is expanded, then the size of the dialog
variables T9 in wkonvert.txt has to be adapted accordingly.
See also
Start-up of code carrier (Page 258)
6.2.2 Structure of the paramtm.ini file
Directory
Directory ...\user\paramtm.ini
Note
Until now, the mmc2\paramtm.ini parameter settings for tool management only contained
comments consisting of documentation of the individual entries. Almost all comments had to
be removed, as new entries caused the critical file length limit of around 63KB to be
exceeded.
A version of paramtm.ini with comments can now be found in mmc2\paramtm.txt.
Overshooting and other errors when reading the parameterization are logged as before in
the ...\user\paramtm.out file.
A comment can be inserted at the end of entries using a semicolon ";".
Structure of the file
[ACCESSLEVEL]
SKAVTIVTM=7
; Activates TM in the PARAM application
SKMGLIST=7
; Displays the magazine list
