Diagnostics and service
5.1 Installing HMI software on a PG/PC
HMI Advanced (IM4)
134 Commissioning Manual, 03/2009, 6FC5397-0DP10-3BA0
8. On confirmation the copy operation starts
9. At the end of the copying operation, you are prompted to restart the PC.
Note
Installing on a PC/PG:
HMI-Advanced can then only be run under a non-administrator user, if this user has write
privileges for directory mmc2 of HMI-Advanced. The installation of HMI-Advanced does not
provide these privileges.
5.1.1 NCU Connection Wizard
Use
The NCU Connection Wizard is only installed during the installation of HMI-Advanced on a
PG/PC. This assists you during the commissioning of the NCK, PLC and drive and during
the configuration of interfaces and the cabling.
With the Connection Wizards, connections are possible both via MPI and Ethernet,
depending on the control unit. Use an Ethernet connection for SINUMERIK solution line and
an MPI connection for SINUMERIK powerline. The type of connection depends on the
software installed on the 840Di control unit.
Starting the "NCU Connection Wizard"
The Connection Wizard is started under "Start menu" → "NCU Connection Wizard" or it is
automatically started after a message if no connection to the control unit can be established.
Note
Changes that you made using the "NCU Connection Wizard" only take effect after a system
restart.
5.1.2 Starting HMI-Advanced in a separate desktop
Overview
Installing HMI-Advanced on a standard PC creates boundary conditions which cause the
following effects when other programs are used:
● Windows that cannot be moved or minimized
● Special keyboard and keyboard filter functions
● Overcrowded task bar
● Changes to color scheme
