Programming
2.5 Softkey menus
Expanding the user interface
2-56 Commissioning Manual, 11/2006, 6FC5397-0DP10-0BA0
Syntax: SK =
(Text[, Access level][, Status])
Description: Define softkey
Parameters: SK softkey, e.g., HS1 to HS8, VS1 to VS8
Text Enter text
Display file name "\\my_pic.bmp"
or via separate text file $85199, e.g., with the
following text in the (language-specific) text file:
85100 0 0 "\\c:\pic\my_pic.bmp".
Size of image, which can be displayed on a
softkey:
max. 80 x 34 pixels
Access level ac0 to ac7 (ac7: default)
Status se1: visible (default)
se2: disabled (gray text)
se3: displayed (last softkey used)
Note
Enter %n in the softkey text to create a line break.
A maximum of 2 lines of 10 characters each are available in HMI Advanced and 2 lines of 9
characters each in HMI Embedded sl.
Assigning the security level
The operator can only access information on the level for which he is authorized and all
lower levels.
The meanings of the different protection levels are as follows: ac0 is the highest protection
level and ac7 the lowest.
Security level Locked by range
ac0 Password Siemens
ac1 Password Machine manufacturer
ac2 Password Service
ac3 Password User
ac4 Keylock switch position 3 Programmer, machine setter
ac5 Keylock switch position 2 Qualified operator
ac6 Keylock switch position 1 Trained operator
ac7 Keylock switch position 0 Semi-skilled operator
